655 Parts
To help us find your part, look through the images of your particular machine, then copy and paste the item no. part number description into the Parts Finder text box under – List the parts you need. Assemblies at the bottom, please scroll down.
ITEM NO. PART NUMBER DESCRIPTION
Copy and paste the part’s – item no. part number description – into the Parts Finder text box under – List the parts you need. Then click NEXT to complete the form. Assemblies at bottom, please scroll down.
l 45080-01 MC 655 FRAME WELDMENT
2 45082-01 MC 655 HOPPER
3 HHCS 3/8-16 UNC x 2-1 /4″ LG.
4 HHCS, 5/16-18 UNC x l ” LG.
5 HHCS, l/2-13UNCxl-l/2″LG.
6 HHCS, 1/2-13 UNC x 1- 1/4″ LG.
7 HHCS, 3/8-16 UNC x 3/4″ LG.
8 HHCS, 1 /2-13 UNC x 3″ LG.
9 HHCS, 3/8-16 UNC x 1-3/4″ LG.
10 HHCS, 5/16-18 UNC x 1-1 /2″ LG.
11 HHCS, 1 /4-20 UNC x 1-1 /4″ LG.
12 HHCS, 1/4-20 UNC x 1-1/2″ LG.
13 HHCS, 3/8-16 UNC x 4″ LG.
14 HHCS, 1 /2-20 UNF x l” LG.
15 HHCS, 1 /2-13 UNC x 3-3/4″ LG.
16 HHCS, 1 /2-13 UNC x 4″ LG.
17 HHCS, l /2-13 UNC x 1-3/4″ LG.
18 HHCS, 3/8-16 UNC x 2-1 /2″ LG.
19 BATTERY BOX HARDWARE
20 HHCS, 3/8-16 x 1″ LG.
21 FLAT WASHER, 1/2″
22 FLAT WASHER, 3/8″
23 FLAT WASHER, 3/4″
24 LOCK NUT, 3/8-16 UNC
25 WING NUT, l /2-13 UNC
26 45012-13 HOPPER CLAMP
27 45145-20 ENGINE COVER W / LABELS
28 45145-10 ENGINE COVER BRACE
29 MS0200 RUBBER HOOD LATCH
30 45145-17 RETRACTABLE PLUNGER
31 SAE FLAT WASHER, 5/16″
32 SAE FLAT WASHER, 3/8″
33 SAE FLAT WASHER, 1/2″
34 NYLOK LOCK NUT, 5/16-18 UNC
35 45082-06 PLUNGER FOR MC 655
36 45008-01 CURBILDER MOTOR MOUNT
37 EN1700 13 HP HONDA, ELECTRIC ST ART
38 BE0l00 1-1 /4″ 2-BOLT FLANGE BEARING
39 BE0200 1-1 /4″ 4-BOLT FLANGE BEARING
40 45050-23 COG “V” BELT
41 45050-16 OUTPUT SHAFT
42 45008-10 SHEAVE GAURD BRACKET
43 45024-03 SAFETY TORQUE ARM
44 45048-07 CLUTCH, 1″ BORE, STD. DUTY
45 45050-02 2 GROOVE Q.D. SHEAVE
46 45050-03 Q.D. BUSHING FOR 4050-02
47 45050-05 GEAR REDUCER
48 45024-04 SAFETY TORQUE ARM BRACKET
49 45024-02 TORQUE ARM COMPRESSION SPRING
50 45024-09 SAFETY TORQUE ARM HANDLE
51 45024-14 SAFETY TORQUE ARM STUD
52 LOCK WASHER, l /2″
53 LOCK WASHER, 3/8″
54 HEX NUT, 1 /2-13 UNC
55 HEX NUT, 5/8-11 UNC
56 HEX NUT, 3/8-16 UNC
57 45016-17 IDLER BRACKET WELDMENT
58 45016-21 IDLER BRACKET TUBE
59 SK0200 15 TOOTH SPROCKET
60 45132-43 THROTTLE CONTROL
61 45130-23 13HP HONDA THROTTLE MOUNTING
62 SHOULDER BOLT, 5/8-11 UNC x 3/4 DIA x 2″ LG.
63 45016-18 IDLER BRACKET RETAINING PLATE
64 45132-44 BULK HEAD FITTING
65 45130-27 HONDA THROTTLE WIRE SWIVEL
66 45130-24 13 HP HONDA THROTTLE CABLE ASSEMBLY
67 LOCK NUT, 5/16-18 UNC
68 LOCK NUT, 1 /4-20 UNC
69 45016-10 IDLER SPROCKET W / BUSHING
70 45050-25 ROLLER CHAIN, MC655 60-5/8″ LG.
71 45108-07 3/8″ CAGE NUT
72 45033-01 REAR JACK CLAMP BRACKET, SQUARE TUBE
73 45034-03 REAR JACK COVER WELDMENT
74 45039 REAR WHEEL FORK, SHORT
75 BE0600 JACK ASSEMBLY THRUST BEARING
76 45034-15 SHORT ADJUSTING SCREW WELDMENT
77 47132-24 CARRIAGE BOLT, 1 /2-13 UNC x 3-1 /2″ LG.
78 47139-37 CARRIAGE BOLT, 1 /2-13 UNC x 3″ LG.
79 45036-11 JACK HANDLE ASSEMBLY
80 WT0l00 8″ x 2″ RUBBER WHEEL W / ROLLER BEARING
81 45094-04 AXEL 3/4-1 0NC x 10″ LG W / LOCKNUTS
82 LOCK NUT, 1 /2-13 UNC
83 MS0400 JACK HANDLE KNOB
84 45005-02 FRONT JACK HOUSING
85 45038-01 MC-550/650 FRONT WHEEL FORK
86 45020-13 STEERING HANDLE W/ GRIPS
87 45059-04 MALE TIE ROD END W / STUD
88 45059-11 COUPLING NUT, l /2-20 UNF x 1-1 /4″ LG.
89 45059-08 TIE ROD
90 45031-18 MARKER HOLDER ROD BRACKET
91 45031-11 MC-550/650/850 MARKER POINTER
92 45031-17 CURBER MARKING ROD BACKPLATE
93 45031-21 FRONT END CLAMP RETAINING NUT
94 45140-31 FRONT END CLAMP WASHER
95 CG0l00 GRIP, HANDLEBAR
96 45083-01 MC 655 AUGER HOUSING
97 BE0200 1-1 /4″ 4-BOLT FLANGE BEARING
98 45014-01 6″ COMPACTION TUBE
99 45018-09 6″ SOLID AUGER, 9″ LONG
100 45023-01 SOLID AUGER SHAFT
101 SK0300 23 TOOTH SPROCKET
102 45081-01 MC 655 CHAIN GUARD
103 BTOl 00 BATTERY; 12V DC
104 45116-21 BATTERY BOX TOP
105 45116-20 BATTERY BOX BOTTOM
106 45116-19 WRAP-AROUND BATTERY BOX SIDE
107 45116-23 BATTERY BOX BOLTS
108 BF0lO0 36″ BATTERY POSITIVE CABLE
109 BF0200 BATTERY GROUND CABLE
110 45043-04 EMERGENCY STOP SWITCH, ELECTRIC START
111 45019-19 LEFT HAND BELT GUARD WELDMENT
112 45019-18 RIGHT HAND BELT GUARD WELDMENT
113 45019-29 CENTER BELT GUARD COVER
114 44108-06 MANUAL TUBE MOUNTING CLAMPS
115 44108-01 MANUAL TUBE
116 44108-05 MANUAL TUBE CAP
